Part 21 - Policy Gradient Methods in Reinforcement Learning

Machine Learning Algorithms Series - Implementing REINFORCE with TensorFlow and Gym

Following our exploration of Deep Q-Networks (DQN), this article delves into policy gradient methods, a different class of reinforcement learning algorithms. Unlike Q-learning-based methods that learn Q-values, policy gradient methods directly learn a policy by optimizing the parameters of a policy network. This approach focuses on finding the optimal action selection strategy that maximizes cumulative rewards. We'll implement the REINFORCE algorithm using TensorFlow and Gym.

Understanding Policy Gradient Methods

• Direct Policy Optimization: Policy gradient methods directly optimize the policy parameters instead of indirectly optimizing a value function.

• Action Sampling: Actions are sampled from a policy distribution.

• Gradient-Based Updates: The policy is updated using gradients based on rewards.

• REINFORCE Algorithm: A popular policy gradient method where the policy is updated using gradients based on rewards.

Step-by-Step Implementation of REINFORCE

1. Importing Libraries:

   • numpy for arrays and numerical computations.

   • tensorflow (as tf) and tensorflow.keras.layers for building the neural network.

   • gym for the environment interface.

2. Setting up the Environment:

   • Create the Gym environment (e.g., "CartPole-v1").

   • Get the number of state features from env.observation_space.shape.

   • Define the number of possible actions from env.action_space.n.

3. Defining Hyperparameters:

   • learning_rate: Step size for the optimizer (e.g., 0.01).

   • gamma: Discount factor for future rewards (e.g., 0.99).

4. Building the Policy Network:

   • Use tf.keras.Sequential to create a sequential model.

   • Add dense layers with ReLU activation for hidden layers.

   • Include an output layer with a number of actions and softmax activation to provide a probability distribution over actions.

   • Compile the model with the Adam optimizer.

5. Creating the Action Selection Function:

   • Reshape the state for model input compatibility.

   • Use the policy model to predict the probability distribution over actions.

   • Choose an action based on the predicted probabilities using np.random.choice.

6. Discounted Reward Calculation:

   • Calculate discounted rewards to account for future rewards.

   • Normalize discounted rewards by subtracting the mean to stabilize training.

7. Training Function:

   • Calculate discounted rewards for the episode.

   • Use tf.GradientTape for automatic differentiation.

   • Calculate action probabilities for each state.

   • Prepare indices to select the probability of the action taken.

   • Extract action probabilities for the chosen actions.

   • Calculate the policy gradient loss.

   • Compute gradients and apply them to update the model's parameters.

8. Main Training Loop:

   • Iterate through a specified number of episodes.

   • Reset the environment at the start of each episode.

   • Choose an action using the policy.

   • Take the action in the environment and get the resulting state, reward, and done flag.

   • Store the state, chosen action, and received reward.

   • Update the state to the next state.

   • When the episode ends, convert episode states into a NumPy array and train on the episode.

   • Log the episode number and total reward.

Complete Code Example:

import numpy as np
import tensorflow as tf
from tensorflow.keras import layers
import gym

# Set up the environment
environment = gym.make("CartPole-v1")
state_shape = environment.observation_space.shape
num_actions = environment.action_space.n

# Define hyperparameters
learning_rate = 0.01
gamma = 0.99

# Build the policy network
def build_policy_model():
    model = tf.keras.Sequential([
        layers.Dense(24, activation='relu', input_shape=(state_shape,)),
        layers.Dense(24, activation='relu'),
        layers.Dense(num_actions, activation='softmax')
    ])
    model.compile(optimizer=tf.keras.optimizers.Adam(learning_rate=learning_rate))
    return model

policy_model = build_policy_model()

# Action selection function
def choose_action(state):
    state = state.reshape([1, state_shape])
    probabilities = policy_model.predict(state)
    action = np.random.choice(num_actions, p=probabilities)
    return action

# Discounted reward calculation
def discounted_rewards(rewards):
    discounted = np.zeros_like(rewards)
    cumulative = 0
    for i in reversed(range(len(rewards))):
        cumulative = cumulative * gamma + rewards[i]
        discounted[i] = cumulative
    discounted -= np.mean(discounted)  # Normalize
    return discounted

# Training function
def train_on_episode(states, actions, rewards):
    discounted_rewards_val = discounted_rewards(rewards)
    with tf.GradientTape() as tape:
        action_probabilities = policy_model(states, training=True)
        action_indices = tf.stack([tf.range(len(actions)), actions], axis=1)
        selected_action_probabilities = tf.gather_nd(action_probabilities, action_indices)
        loss = -tf.reduce_mean(tf.math.log(selected_action_probabilities) * discounted_rewards_val)

    gradients = tape.gradient(loss, policy_model.trainable_variables)
    policy_model.optimizer.apply_gradients(zip(gradients, policy_model.trainable_variables))

# Main training loop
num_episodes = 1000
for episode in range(num_episodes):
    state, _ = environment.reset()
    episode_states, episode_actions, episode_rewards = [], [], []
    done = False

    while not done:
        action = choose_action(state)
        next_state, reward, done, truncated, _ = environment.step(action)
        done = done or truncated

        episode_states.append(state)
        episode_actions.append(action)
        episode_rewards.append(reward)

        state = next_state

    episode_states = np.vstack(episode_states)
    episode_actions = np.array(episode_actions, dtype=np.int32)

    train_on_episode(episode_states, episode_actions, episode_rewards)

    total_reward = sum(episode_rewards)
    print(f"Episode {episode + 1}, Total Reward: {total_reward}")

Conclusion

Policy gradient methods offer a powerful alternative to value-based methods like DQN. By directly optimizing the policy, these methods can handle continuous action spaces and complex environments. The REINFORCE algorithm, as implemented in this article, provides a clear example of how policy gradients can be used to train an agent to maximize cumulative rewards. This approach is fundamental in reinforcement learning and serves as a building block for more advanced policy gradient algorithms.
